About the Product
Agile UST laser display
Project your vision, with an affordable, large screen display up to 150" that will enhance engagement, learning and productivity.
Whatever the size of class or meeting room, unrestricted and immersive presentations are possible with this bright, clear, compact and affordable display solution.
The EB-760W's bright image, scalable up to 150", is clearly visible from any angle and from a distance, and content can be easiliy shared or streamed directly from multiple devices for the perfect collaborative experience.
The EB-760W's ultra short throw lens allows safe, discreet positioning close to the display, enabling presenters free access to perform without casting shadows.
Versatile wired and wireless connectivity options, including screen mirroring via Miracast, allow participants to effortlessly share content from their PCs or mobile devices. With a connected optional Epson visualiser, documents, presentations or 3D objects can be viewed with incredible detail.
With 4,100 lumens Colour Light Output and Epson 3LCD technology, the display is bright and vibrant up-to 150", clearly visible from all angles and from a distance. The experience is immersive and user-friendly.
Unlike a flat-panel display, there is no heavy, breakable, glass panel to create disruptive, reflected blind spots at certain angles, and teachers are not subjected to LCD panel direct blue light radiation, believed to damage eyes. Paired with a hygienic, antibacterial whiteboard, teachers can annotate presentations with dry-wipe pens, or to save energy, simply use the whiteboard with the display turned off.
Projection also enables flexible display sizes, scalable from 49-150", display sizes can be optimised for each room with one familiar product and at a fixed cost.
Projector | |
---|---|
Heat dissipation | 895 BTU/h |
Keystone correction, horizontal | -3 - 3° |
Keystone correction, vertical | -3 - 3° |
Vertical scan range | 100 - 120 Hz |
Projector brightness (economic mode) | 2800 ANSI lumens |
Number of colours | 1.07 billion colours |
Screen size compatibility | 1524 - 3810 mm (60 - 150") |
Supported aspect ratios | 16:10 |
Native aspect ratio | 16:10 |
Contrast ratio (typical) | 2500000:1 |
Projector native resolution | 1080p (1920x1080) |
Projection technology | 3LCD |
Projector brightness | 4100 ANSI lumens |
Light source | |
---|---|
Service life of light source (economic mode) | 30000 h |
Service life of light source | 20000 h |
Light source type | Laser/LED hybrid |
Lens system | |
---|---|
Throw ratio | 0.27 - 0.37:1 |
Zoom ratio | 1.35:1 |
Zoom capability | Yes |
F-number (relative aperture) | 1.6 |
Fixed focal length | 3.7 mm |
Focus | Manual |
Video | |
---|---|
Video colour modes | Blackboard, Cinema, Dynamic, Presentation, sRGB |
3D | No |
Full HD | Yes |
Ports & interfaces | |
---|---|
Audio Return Channel (ARC) | Yes |
Consumer Electronics Control (CEC) support | Yes |
Serial interface type | RS-232C |
Microphone in | Yes |
Audio (L/R) out | 1 |
Audio (L/R) in | 3 |
USB 2.0 Type-B ports quantity | 1 |
USB 2.0 Type-A ports quantity | 2 |
USB 2.0 ports quantity | 3 |
DVI port | No |
Composite video in | 1 |
HDMI ports quantity | 3 |
VGA (D-Sub) ports quantity | 2 |
Network | |
---|---|
Miracast | Yes |
Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
Wi-Fi | Yes |
Ethernet LAN (RJ-45) ports | 1 |
Ethernet LAN data rates | 10,100 Mbit/s |
Ethernet LAN | Yes |
Storage | |
---|---|
Card reader integrated | No |
Features | |
---|---|
Screen mirroring | Yes |
On Screen Display (OSD) | Yes |
Noise level (economic mode) | 27 dB |
Noise level | 37 dB |
Multimedia | |
---|---|
RMS rated power | 16 W |
Built-in speaker(s) | Yes |
Design | |
---|---|
Cable lock slot | Yes |
Cable lock slot type | Kensington |
Product colour | White |
Market positioning | Presentation |
Product type | Ultra short throw projector |
Display | |
---|---|
Built-in display | No |
Power | |
---|---|
AC input frequency | 50/60 Hz |
AC input voltage | 100 - 240 V |
Power consumption (PowerSave) | 199 W |
Power consumption (max) | 263 W |
Power consumption (standby) | 0.5 W |
Power consumption (typical) | 197 W |
Power source | AC |
Supplier features | |
---|---|
Recommended gender | Any gender |
Operational conditions | |
---|---|
Storage relative humidity (H-H) | 10 - 90% |
Operating relative humidity (H-H) | 20 - 80% |
Storage temperature (T-T) | -10 - 60 °C |
Weight & dimensions | |
---|---|
Weight | 5.9 kg |
Packaging content | |
---|---|
Cables included | AC |
Manual | Yes |
Batteries included | Yes |
Remote control included | Yes |
Technical details | |
---|---|
Warranty period | 5 year(s) |
